Product Model
gr-m5x2-b
Selling Points
- 1The Festo GR-M5X2-B one-way flow control valve ensures stable and controlled airflow, reducing the strain on pneumatic components and extending their service life.
- 2With a standard nominal flow rate of 95 l/min in the flow control direction and 75 l/min in the non-return direction, this valve provides precise control over airflow.
- 3The valve operates within a pressure range of 0.5 to 10 bar and is designed to handle compressed air as per ISO 8573-1:2010, making it suitable for various industrial applications.
- 4The GR-M5X2-B features a knurled screw adjusting element and is available in a compact design with a nominal width of 2 mm, making it easy to integrate into any pneumatic system.
- 5The valve is constructed from high-quality materials, including wrought aluminum alloy and NBR seals, ensuring durability and reliability in harsh environments. It also meets ATEX Zone 1, Zone 2, Zone 21, and Zone 22 standards for explosion prevention and protection.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Valve function | Flow control non-return function | Pneumatic connection 1 | M5 |
Pneumatic connection 2 | M5 | Adjusting element | Knurled screw |
Type of mounting | Optionally: Front panel mounting With through-hole | Standard nominal flow rate in flow control direction | 95l/min |
Standard nominal flow rate in non-return direction | 75l/min | Operating pressure | 0.5bar 10bar |
Ambient temperature | -20°C 60°C | Housing material | Wrought aluminum alloy |
Explosion prevention and protection | Observe the information on the certificate Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) | Mounting position | Any |
Symbol | 00991931 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Temperature of medium | -20°C 60°C | Nominal width | 2mm |
Product weight | 37g | Note on materials | RoHS-compliant |
Seals material | NBR | Sleeve material | POM |
Material of adjusting screw | High-alloy steel | Nut material | Wrought aluminum alloy |
Manufacturer ID | 152611 |
Specifications may be subject to change without notice
