Product Model
grr-1/2
Selling Points
- 1The Festo GRR-1/2 one-way flow control valve is made from durable wrought aluminum alloy, ensuring long-lasting performance in various industrial environments.
- 2This valve features a roller lever adjustment component for easy and precise control of pneumatic flow, making it ideal for applications requiring high accuracy.
- 3With a standard nominal flow rate of 1300 liters per minute in the flow control direction and 1250 liters per minute in the non-return direction, the GRR-1/2 valve offers efficient and reliable operation.
- 4The valve operates within a wide pressure range, from 0.3 bar to 10 bar, making it versatile for various pneumatic systems and applications.
- 5The compact dimensions of 117 x 34 mm make the Festo GRR-1/2 valve easy to integrate into tight spaces, enhancing its usability in diverse industrial settings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Valve function | Flow control non-return function | Pneumatic connection 1 | G1/2 |
Pneumatic connection 2 | G1/2 | Adjusting element | Roller lever |
Type of mounting | With through-hole | Standard nominal flow rate in flow control direction | 1300l/min |
Standard nominal flow rate in non-return direction | 1250l/min | Operating pressure | 0.3bar 10bar |
Ambient temperature | -10°C 60°C | Housing material | Wrought aluminum alloy |
Mounting position | Any | Symbol | 00991465 |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
LABS (PWIS) conformity | VDMA24364-B2-L | Temperature of medium | -10°C 60°C |
Product weight | 735g | Manufacturer ID | 2111 |
Specifications may be subject to change without notice
