Product Model
he-2-qs-8
Selling Points
- 1The Festo HE-2-QS-8 is a 2/2 double solenoid valve, ensuring precise and reliable pneumatic control in various industrial settings.
- 2Equipped with manual actuation, this valve offers flexibility and ease of operation, making it suitable for a wide range of applications.
- 3The valve features pneumatic connections at ports 1QS-8 and 2QS-8, allowing for efficient integration into complex systems.
- 4Designed for high flow rates, the HE-2-QS-8 supports up to 415 liters per minute, making it ideal for demanding industrial processes.
- 5Manufactured by Festo, a renowned brand in industrial automation, the HE-2-QS-8 ensures top-quality performance and durability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Valve function | 2/2 bistable | Pneumatic connection 1 | QS-8 |
Pneumatic connection 2 | QS-8 | Actuation type | Manual |
Type of mounting | Optionally: Direct mounting via through-hole Line installation | Standard nominal flow rate | 415.8l/min |
Nominal width | 3.5mm | Operating pressure | -0.95bar 10bar |
Ambient temperature | 0°C 60°C | Housing material | PBT-reinforced |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Sealing principle | Soft |
Mounting position | Any | Structural design | Piston gate valve |
Type of control | Direct | Flow direction | Reversible |
Symbol | 00997328 | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Cleanroom class | Class 4 according to ISO 14644-1 | Temperature of medium | 0°C 60°C |
Product weight | 26g | Note on materials | RoHS-compliant |
Seals material | NBR | Manufacturer ID | 153468 |
Specifications may be subject to change without notice
