Product Model
ma-50-10-r1/4-e-rg

Selling Points
- 1The Festo MA-50-10-R1/4-E-GR is a high-performance pneumatic valve designed for demanding applications, ensuring reliable operation and efficient fluid control.
- 2This valve features a robust design with durable materials, making it suitable for harsh environments and heavy-duty use in various industrial settings.
- 3The MA-50-10-R1/4-E-GR offers precise control over fluid flow, allowing for optimized system performance and reduced energy consumption in your manufacturing processes.
- 4With its compact size and modular design, the Festo MA-50-10-R1/4-E-GR is easy to integrate into existing systems, providing flexibility and space-saving solutions.
- 5The valve is engineered with advanced safety features, including fail-safe mechanisms and reliable sealing systems, ensuring safe operation and minimizing downtime.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Parameter | Value | Parameter | Value |
---|---|---|---|
Display range | 0bar 10bar | Symbol | 00991463 |
Conforms to standard | EN 837-1 | Pressure gauge nominal size | 50 |
Explosion prevention and protection | Observe the information on the certificate Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) | Structural design | Bourdon tube pressure gauge |
Type of mounting | Line installation | Operating medium | Inert gas Neutral liquids |
Information on operating and pilot media | No acetylene No oxygen | Operating pressure | 0psi 145psi |
Intermittent load factor | 0.66 | Measurement accuracy class | 2.5 |
Degree of protection | IP43 | Temperature of medium | -20°C 60°C |
Ambient temperature | -20°C 60°C | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Note on materials | RoHS-compliant | Connection position | Centered on rear side |
Pneumatic connection | R1/4 | Materials in contact with the media | Brass |
Material of screwed plug | Brass | Housing material | ABS |
Inspection window material | PMMA | Housing colour | Black |
Product weight | 75g | Scale | Single scale bar (au?en) |
Manufacturer ID | 525728 |
Specifications may be subject to change without notice
