Product Model
ma-50-16-r1/4-e-rg
Selling Points
- 1The Festo MA-50-16-R1/4-E-rg is a high-performance air preparation module engineered to provide clean and dry compressed air for various industrial applications.
- 2This module features a compact design, making it ideal for space-constrained environments while maintaining exceptional air quality and flow rates.
- 3The MA-50-16-R1/4-E-rg is equipped with advanced filtration systems, ensuring that the compressed air is free from contaminants and moisture, which is crucial for precise pneumatic systems.
- 4With its robust construction and durable components, this air preparation module offers long-lasting performance and reliability in demanding industrial settings.
- 5The Festo MA-50-16-R1/4-E-rg is part of Festo's extensive range of pneumatic components, ensuring compatibility and seamless integration with other Festo products for comprehensive system solutions.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Display range | 0bar 16bar | Symbol | 00991463 |
Conforms to standard | EN 837-1 | Pressure gauge nominal size | 50 |
Explosion prevention and protection | Observe the information on the certificate Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) | Structural design | Bourdon tube pressure gauge |
Type of mounting | Line installation | Operating medium | Inert gas Neutral liquids |
Information on operating and pilot media | No acetylene No oxygen | Operating pressure | 0psi 232psi |
Intermittent load factor | 0.66 | Measurement accuracy class | 2.5 |
Degree of protection | IP43 | Temperature of medium | -20°C 60°C |
Ambient temperature | -20°C 60°C | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Note on materials | RoHS-compliant | Connection position | Centered on rear side |
Pneumatic connection | R1/4 | Materials in contact with the media | Brass |
Material of screwed plug | Brass | Housing material | ABS |
Inspection window material | PMMA | Housing colour | Black |
Product weight | 75g | Scale | Single scale bar (au?en) |
Manufacturer ID | 525729 |
Specifications may be subject to change without notice
