Product Model
ms12-frm
Selling Points
- 1The Festo MS12-FRM branching module supports a standard nominal flow rate of 25,000 to 42,000 liters per minute, making it suitable for high-demand pneumatic systems.
- 2With an operating pressure range of 0 to 20 bar, this module ensures consistent and reliable air distribution, crucial for maintaining system performance.
- 3The MS12-FRM offers optional mounting positions, providing flexibility in system design and installation.
- 4Featuring a corrosion resistance class of 2, the module is designed to withstand moderate corrosion stress, ensuring durability in various industrial environments.
- 5Constructed with die-cast aluminum, the module is both lightweight and robust, making it an efficient choice for pneumatic system components.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Mounting position | Any | Structural design | Branching module |
Symbol | 00991510 | Operating pressure | 0bar 20bar |
Standard nominal flow rate in main flow direction 1 -> 2 | 25000l/min 42000l/min | Operating medium | Compressed air as per ISO 8573-1:2010 [-:-:-] |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Storage temperature | -10°C 60°C | Temperature of medium | -10°C 60°C |
Ambient temperature | -10°C 60°C | Pneumatic connection 4 | G1 |
Housing material | Die-cast aluminum | Manufacturer ID | 535035 |
Specifications may be subject to change without notice
