Product Model
ms4-lr
Selling Points
- 1The Festo MS4-LR offers advanced motion control with high precision and reliability, ensuring smooth and efficient operation in industrial automation applications.
- 2Equipped with advanced servo technology, the MS4-LR provides fast and precise positioning, making it ideal for complex manufacturing processes.
- 3Designed for durability and longevity, the MS4-LR is built to withstand harsh industrial environments, minimizing downtime and maintenance needs.
- 4The MS4-LR integrates seamlessly with Festo's comprehensive automation solutions, enhancing overall system performance and efficiency.
- 5With its user-friendly interface and advanced diagnostic tools, the MS4-LR simplifies setup and troubleshooting, reducing operational costs and improving productivity.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 4 | Series | MS |
Actuator lock | Rotary knob with detent Rotary knob with integrated lock can be closed with accessories | Mounting position | Any |
Structural design | Pressure regulator with pressure gauge | Controller function | Outlet pressure constant With secondary exhausting With return flow function |
Pressure gauge | G1/4 prepared G1/8 prepared with pressure sensor with pressure gauge | Operating pressure | 0.8bar 14bar |
Pressure regulation range | 0.3bar 12bar | Max. pressure hysteresis | 3.625psi |
Standard nominal flow rate | 1000l/min 2200l/min | Certification | c UL us - Recognized (OL) |
CE marking (see declaration of conformity) | as per EU explosion protection directive (ATEX) | UKCA marking (see declaration of conformity) | acc. to UK EX instructions |
Explosion protection certification outside the EU | EPL Db (GB) EPL Gb (GB) | Explosion prevention and protection | Zone 1 (ATEX) Zone 1 (UKEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 21 (UKEX) Zone 22 (ATEX) |
ATEX category gas | II 2G | ATEX category for dust | II 2D |
Type of ignition protection for gas | Ex h IIC T6 Gb X | Type of (ignition) protection for dust | Ex h IIIC T60°C Db X |
Explosive ambient temperature | -10°C <= Ta <= +60°C | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] Inert gas |
Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Storage temperature | -10°C 60°C |
For use in the food industry | See supplementary material information | Temperature of medium | -10°C 60°C |
Ambient temperature | -10°C 60°C | Product weight | 225g |
Type of mounting | Optionally: Front panel mounting Line installation With accessories | Note on materials | RoHS-compliant |
Material of sub-base | Die-cast aluminum | Seals material | NBR |
Housing material | Die-cast aluminum | Diaphragm material | NBR |
Manufacturer ID | 527690 |
Specifications may be subject to change without notice
