Product Model
ms6n-lfr-1/4-d7-eum-as
Selling Points
- 1The MS6N-LFR-1/4-D7-EUM-AS filter regulator offers high flow rates, ensuring efficient air supply in industrial applications. It can handle pressures up to 176 psi, making it suitable for demanding environments.
- 2With a corrosion resistance class 2 according to Festo standard 940 070, this filter regulator is designed to withstand moderate corrosion, making it ideal for use in industrial environments where exposure to coolants or lubricating agents is common.
- 3The MS6N-LFR-1/4-D7-EUM-AS features four pressure regulation ranges, including D7, which spans from 0.5 to 12 bar. This flexibility allows for precise control over output pressure, ensuring optimal performance in various applications.
- 4Equipped with a filtration grade of 5 μm, this filter regulator provides excellent filtration capabilities, ensuring clean air supply and extending the lifespan of pneumatic systems.
- 5The MS6N-LFR-1/4-D7-EUM-AS offers various mounting options, including lockable rotary knobs and long rotary knobs, making it easy to integrate into control panels or other industrial setups.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 6 | Series | MS |
Actuator lock | Rotary knob with detent can be closed with accessories | Mounting position | Vertical +/- 5° |
Grade of filtration | 40μm | Condensate drain | Manually rotating |
Structural design | Filter regulator with pressure gauge | Max. condensate volume | 38ml |
Controller function | Outlet pressure constant With secondary exhausting | Bowl guard | Integrated as metal bowl guard |
Degree of condensate separation | 75% | Symbol | 00991589 |
Pressure gauge | with pressure gauge | Operating pressure | 0.8bar 20bar |
Pressure regulation range | 0.5bar 12bar | Max. pressure hysteresis | 3.625psi |
Standard nominal flow rate | 2500l/min | Operating medium | Compressed air as per ISO 8573-1:2010 [-:4:-] Inert gas |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Storage temperature | -10°C 60°C | For use in the food industry | See supplementary material information |
Air quality class at the output | Compressed air as per ISO 8573-1:2010 [7:4:4] | Temperature of medium | -10°C 60°C |
Ambient temperature | -10°C 60°C | Pore size | 40μm |
Product weight | 1087g | Type of mounting | Optionally: Front panel mounting Line installation With accessories |
Pneumatic connection 1 | 1/4 NPT | Pneumatic connection 2 | 1/4 NPT |
Note on materials | RoHS-compliant | Material of operator panel | PA POM |
Seals material | NBR | Compressed air filter material | PE |
Housing material | Die-cast aluminum | Diaphragm material | NBR |
Material of bowl | Wrought aluminum alloy | Separating disc material | POM |
Manufacturer ID | 531329 |
Specifications may be subject to change without notice
