Product Model
ms6-wp-f1a
Selling Points
- 1The MS6-WP-F1A mounting bracket features a corrosion resistance class of CRC 2, ensuring it can withstand moderate corrosion stress in demanding environments.
- 2Designed for in-line installation or via mounting bracket, the MS6-WP-F1A offers flexibility in mounting options, making it easy to integrate into your pneumatic system.
- 3Made from RoHS-compliant materials, the MS6-WP-F1A ensures compliance with environmental regulations, making it a sustainable choice for your automation needs.
- 4With a product weight of 76 grams, the MS6-WP-F1A is a compact and lightweight solution that can be easily integrated into your system without adding bulk.
- 5Suitable for various pneumatic applications, including the production of lithium-ion batteries, the MS6-WP-F1A is a versatile mounting bracket that can handle diverse operational conditions.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 6 | Series | MS |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Suitability for the production of Li-ion batteries | Metals with more than 1% by mass of copper, zinc or nickel are excluded from use.The exceptions are nickel in steel, chemically nickel-plated surfaces, circuit boards, cables, electrical plug connectors and coils | Temperature of medium | -10°C 60°C |
Product weight | 76g | Note on materials | RoHS-compliant |
Seals material | NBR | Module connector material | POM High-alloy stainless steel |
Material of screws | High-alloy stainless steel | Bracket material | Die-cast aluminum |
Manufacturer ID | 8176698 |
Specifications may be subject to change without notice
