Product Model
ms6-wpg
Selling Points
- 1Built with die-cast aluminum bracket for durability and corrosion resistance.
- 2Designed for maximum flow rates with minimal space requirements.
- 3Operates between -10 °C to 60 °C, ensuring versatility in different environments.
- 4Simple connection system saves time and effort during setup.
- 5Meets VDMA24364-B1/B2-L standards and is RoHS-compliant for environmental safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 6 | Series | MS |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Temperature of medium | -10°C 60°C | Product weight | 245g |
Note on materials | RoHS-compliant | Seals material | NBR |
Module connector material | POM Steel | Material of screws | Steel |
Bracket material | Die-cast aluminum | Manufacturer ID | 8072794 |
Specifications may be subject to change without notice
