Product Model
msb4n-1/4-frc1:j5m1
Selling Points
- 1The Festo MSB4N-1/4-FRC1:J5M1 is a service unit designed for filtering and regulating compressed air, ensuring high-quality air supply in industrial applications.
- 2This unit features a 1/8NPT connection and is equipped with a 40-micron filter, providing efficient air purification and maintaining optimal system performance.
- 3The MSB4N-1/4-FRC1:J5M1 includes a manual drain valve, allowing for easy maintenance and ensuring that the system remains free from contaminants.
- 4With a maximum operating pressure of 7 bar, this service unit is suitable for a wide range of industrial applications, including pneumatic systems and automation processes.
- 5The Festo MSB4N-1/4-FRC1:J5M1 is part of Festo's comprehensive range of air preparation units, offering reliable and efficient solutions for maintaining compressed air quality in industrial settings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 4 | Series | MS |
Actuator lock | Rotary knob with integrated lock | Mounting position | Vertical +/- 5° |
Grade of filtration | 40μm | Condensate drain | Manually rotating |
Structural design | Filter regulator with pressure gauge Proportional standard oil mist lubricator | Controller function | Outlet pressure constant With primary pressure compensation With secondary exhausting With return flow function |
Bowl guard | Plastic bowl guard | Symbol | 00991761 |
Pressure gauge | with pressure gauge | Operating pressure | 1.5bar 14bar |
Pressure regulation range | 1bar 12bar | Standard nominal flow rate | 1400l/min |
Operating medium | Compressed air as per ISO 8573-1:2010 [-:4:-] Inert gas | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Storage temperature | -10°C 60°C | For use in the food industry | See supplementary material information |
Air quality class at the output | Compressed air as per ISO 8573-1:2010 [7:4:-] | Temperature of medium | -10°C 60°C |
Ambient temperature | -10°C 60°C | Product weight | 500g |
Type of mounting | With accessories | Pneumatic connection 1 | 1/4 NPT |
Pneumatic connection 2 | 1/4 NPT | Housing material | Die-cast aluminum |
Material of bowl | PC | Manufacturer ID | 533947 |
Specifications may be subject to change without notice
