Product Model
msfw-230-50/60-od
Selling Points
- 1The MSFW-230-50/60-OD solenoid coil offers a power factor of 0.7, ensuring high efficiency in industrial automation applications.
- 2This solenoid coil features an optional mounting position, providing flexibility in installation and integration with various systems.
- 3With a minimum pick-up time of 10 ms, the MSFW-230-50/60-OD ensures quick and reliable operation in demanding industrial environments.
- 4Constructed from high-quality materials, this solenoid coil is designed to withstand ambient temperatures ranging from -5°C to 40°C, ensuring durability and long service life.
- 5Capable of operating at a 100% duty cycle, the MSFW-230-50/60-OD is suitable for continuous operation in industrial automation systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Mounting position | Any | Switching position indication | no |
Min. pick-up time | 10ms | Duty cycle | 100% |
Power factor cos {phi} | 0.7 | Coil characteristics | 230 V AC: 50/60 Hz, initial power 9.0 VA, holding power 7.0 VA |
Permissible frequency fluctuations | +/- 5% | Permissible voltage fluctuations | +/- 10 % |
CE marking (see declaration of conformity) | As per EU low voltage directive | UKCA marking (see declaration of conformity) | To UK instructions for electrical equipment |
LABS (PWIS) conformity | VDMA24364-C1-L | Degree of protection | IP65 |
Ambient temperature | -5°C 40°C | Max. tightening torque of socket | 0.4Nm |
Product weight | 55g | Electrical connection | 3-pin Plug flags with connection diagram as per Festo standard for MSSD-F |
Type of mounting | With knurled nut | Note on materials | RoHS-compliant |
Solenoid coil material | Duroplast Copper Steel | Material of winding | Copper |
Manufacturer ID | 34422 |
Specifications may be subject to change without notice
