Product Model
nedu-l1r2-r3l1g12m22-5l1-1l2-p-n-r3u1g12
Selling Points
- 1The NEDU-L1R2-M12G5-M12LE-1R electrical connector is designed with a Y-distributor configuration, ensuring efficient communication and additional supply in industrial automation systems.
- 2This connector features M12x1 A-coded connections, adhering to the EN 61076-2-101 standard for reliable and secure electrical connections.
- 3With a robust design and materials, including TPE-U(PUR) and PVC, this connector offers high protection against environmental factors such as dust and moisture, rated IP68/IP69K.
- 4The NEDU-L1R2-M12G5-M12LE-1R supports a wide operating voltage range of 0 to 30 V DC, making it suitable for various industrial applications.
- 5This connector is RoHS-compliant and features a low corrosion resistance class (CRC) 1, ensuring it meets stringent environmental and safety standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Conforms to standard | IEC 60603-7-3 | Certification | RCM compliance mark c UL us - Listed (OL) |
Certificate issuing authority | UL E239998 | Cable designation | Without label holder |
Product weight | 520g | Electrical connection 1, function | Field device end |
Electrical connection 1, design | Rectangular | Electrical connection 1, connection type | Plug |
Electrical connection 1, cable outlet | Straight | Electrical connection 1, connection technology | Circuit board connector RJ45 |
Electrical connection 1, number of pins/wires | 12 | Electrical connection 1, occupied pins/wires | 12 |
Electrical connection 1, type of mounting | Screw-type lock | Electrical connection 2, function | Control side |
Electrical connection 2, design | Rectangular | Electrical connection 2, connection type | Plug |
Electrical connection 2, cable outlet | Straight | Electrical connection 2, connection technology | RJ45 |
Electrical connection 2, number of pins/wires | 8 | Electrical connection 2, occupied pins/wires | 8 |
Electrical connection 2, type of mounting | Snap-locking | Electrical connection 2, connection pattern | 00995653 |
Electrical connection 3, function | Control side | Electrical connection 3, design | Rectangular |
Electrical connection 3, connection type | Socket | Electrical connection 3, cable outlet | Straight |
Electrical connection 3, connection technology | USB 2.0 type B | Electrical connection 3, number of pins/wires | 4 |
Electrical connection 3, occupied pins/wires | 4 | DC operating voltage range | 0V 60V |
Current rating at 40° C | 1A | Shield | yes |
Transmission characteristics | In accordance with category 5, EN 50173, class D According to category 5, ISO/IEC 11801, class D | Cable length 1 | 5m |
Cable length 2 | 1m | Cable characteristic | for static applications |
Bending radius, fixed cable installation | 30mm | Cable diameter 1 | 5.6mm |
Cable diameter tolerance 1 | ± 0.2 mm | Cable diameter 2 | 4.5mm |
Cable diameter 2 tolerance | ± 0.2 mm | Degree of protection | IP20 IP66 IP67 |
Note on degree of protection | In mounted state | Ambient temperature | -20°C 55°C |
Storage temperature | -20°C 70°C | Relative air humidity | 5 - 85 % Non-condensing |
CE marking (see declaration of conformity) | As per EU EMC directive As per EU RoHS directive | UKCA marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions |
LABS (PWIS) conformity | VDMA24364 zone III | Note on materials | RoHS-compliant |
Corrosion resistance class (CRC) | 4 - Particularly high corrosion stress (when installed) | Material of cable sheath | PVC |
Color cable sheath | Black | Housing material | PC |
Housing colour | Transparent | Material of screw-type lock | High-alloy stainless steel |
Seals material | TPE-V | Material of pin contacts | Brass, nickel-plated and gold-plated |
Insulating sheath material | PVC | Manufacturer ID | 8155230 |
Specifications may be subject to change without notice
