Product Model
nefv-v12-m12w8-0.6-m12qg5
Selling Points
- 1The Festo Nefv-V12-M12W8-0.6-M12QG5 pneumatic valve is designed for high-precision control in industrial automation applications, ensuring reliable and consistent performance.
- 2This valve features a robust and durable construction, making it suitable for demanding environments and long-term use in various industrial settings.
- 3The Nefv-V12-M12W8-0.6-M12QG5 valve is part of Festo's extensive range of pneumatic components, offering a wide range of configurations to meet specific application needs.
- 4With its advanced design, this valve provides efficient flow regulation and precise pressure control, enhancing the overall efficiency of your industrial processes.
- 5The Festo Nefv-V12-M12W8-0.6-M12QG5 valve is backed by Festo's commitment to quality and reliability, ensuring it meets the highest standards of performance and durability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Type of mounting | With through-hole | Product weight | 157g |
Electrical connection 1, function | Field device end | Electrical connection 1, design | Round |
Electrical connection 1, connection type | Socket | Electrical connection 1, cable outlet | Angled |
Electrical connection 1, connection technology | M12x1 A-coded as per EN 61076-2-101 | Electrical connection 1, number of pins/wires | 8 |
Electrical connection 1, occupied pins/wires | 8 | Electrical connection 1, type of mounting | Screw-type lock |
Electrical connection for input 1, connection pattern | 00992265 | Electrical connection 2, function | Analog output module (green), digital input module (white), analog input module (yellow), digital output module (red) Control side |
Electrical connection 2, design | Round | Electrical connection 2, connection type | 4x plugs |
Electrical connection 2, cable outlet | Straight | Electrical connection 2, connection technology | M12x1 A-coded as per EN 61076-2-101 |
Electrical connection 2, type of mounting | Screw-type lock | DC operating voltage range | 0V 30V |
Nominal operating voltage DC | 24V | DC load voltage operating voltage range | 0V 30V |
Nominal operating voltage DC load voltage | 24 V | Current rating at 40° C | 2A |
Surge resistance | 0.06kV | Cable length | 0.623m |
Cable characteristic | Standard | Connector cable test conditions | Test conditions on request |
Degree of protection | IP65 IP67 | Note on degree of protection | In mounted state |
Ambient temperature | -25°C 80°C | Ambient temperature with flexible cable installation | -5°C 80°C |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Note on materials | RoHS-compliant |
Contamination level | 3 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
Material of cable sheath | TPE-U(PUR) | Color cable sheath | Gray |
Housing material | TPE-U(PUR) | Housing colour | Black |
Material of union nut | Die-cast zinc, nickel-plated | Material of pin contacts | Brass Nickel-plated |
Insulating sheath material | PP | Manufacturer ID | 4787544 |
Specifications may be subject to change without notice
