Product Model
pe-1000
Selling Points
- 1The Festo PE-1000 pressure switch offers precise measurement of relative pressure, ensuring accurate control in industrial applications.
- 2This switch operates effectively within a range of 0 to 1 bar, making it versatile for various pneumatic systems.
- 3Designed to work with compressed air to ISO 8573-1:2010 standards, it ensures reliable performance in industrial environments.
- 4Built with die-cast aluminum and anodized aluminum, the PE-1000 provides robust protection against environmental factors, rated IP62.
- 5Featuring a through-hole mounting option and a 1-meter cable length, the PE-1000 is easy to integrate into your pneumatic setup.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Conforms to standard | EN 60947-5-1 | Symbol | 00991470 |
CE marking (see declaration of conformity) | As per EU low voltage directive | UKCA marking (see declaration of conformity) | To UK instructions for electrical equipment |
Measured variable | Relative pressure | Method of measurement | Pneumatic/electric pressure transducer |
Operating pressure | 0bar 1bar | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
Information on operating and pilot media | Operation with oil lubrication not possible | Ambient temperature | -10°C 50°C |
Switching output | Contact-based | Switching function | Threshold value with fixed hysteresis |
Switching element function | Changeover switch | Switch-on point | 0.05bar |
Switch-off point | 0.05bar | Max. switching output voltage AC | 250V |
Max. switching output voltage DC | 250V | Utilization category for inductive load | AC-14 DC-13 |
Utilization category for ohmic load | AC-12 DC-12 | Electrical connection | 4-wire Cable |
Electrical connection 1, connection type | Cable | Electrical connection 1, connection technology | Open end |
Cable length | 1m | Material of cable sheath | PVC |
Type of mounting | With through-hole | Mounting position | Any |
Pneumatic connection | M5 | Product weight | 230g |
Housing material | Die-cast aluminum Aluminum, anodized | Setting options | Permanently set |
Degree of protection | IP62 | Insulation voltage | 2000V |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Contamination level | 3 |
Manufacturer ID | 3719 |
Specifications may be subject to change without notice
