Product Model
pen-1/2-bl-150-cb
Selling Points
- 1High-Quality Polyethylene Material: Made from durable polyethylene, ensuring long-lasting performance.
- 2Compressed Air and Water Compatible: Suitable for use with compressed air or water, meeting ISO 8573-1:2010 standards.
- 3Standard 1/2 Inch Outer Diameter: Easy to connect with QS plug connectors, ideal for pneumatic systems.
- 4150 Feet Length: Conveniently sized for various industrial applications, reducing the need for multiple pieces.
- 5Blue Color for Easy Identification: Clearly visible blue color makes it easy to identify and manage tubing in complex systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
External-? inches | 1/2 | Bending radius relevant for flow rate | 59.741mm |
Min. bending radius | 32.918mm | Tubing characteristics | Suitable for energy chains |
Operating pressure for entire temperature range | -13.775psi 58psi | Temperature-dependent operating pressure | -13.775psi 145psi |
Information on operating pressure | Water: max. 0.6 MPa at 0 - 50 °C | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) |
LABS (PWIS) conformity | VDMA24364-B2-L | Cleanroom class | Statically installed element, no meaningful evaluation possible according to ISO 14644-1 |
Ambient temperature | -30°C 60°C | Product weight by length | 0.848kg/m |
Pneumatic connection | For plug connection outside diameter 1/2" | Color | Blue |
Shore hardness | D 52 +/-3 | Note on materials | RoHS-compliant |
Material of pneumatic tubing | PE | Manufacturer ID | 569894 |
Specifications may be subject to change without notice
