Product Model
qs-1/2-12-20

Selling Points
- 1The Festo QS-1/2-12-20 pneumatic cylinder is part of Festo's core range, ensuring high-quality components that meet the needs of various automation tasks. Its standardized dimensions and mounting interfaces make it easy to integrate into existing systems.
- 2This cylinder is designed for precision and reliability, offering a robust construction that withstands demanding applications. Its pneumatic design ensures efficient operation and minimal energy consumption, making it an ideal choice for cost-effective automation solutions.
- 3The QS-1/2-12-20 cylinder features a wide range of configurations, including piston rod cylinders, rodless cylinders, and swivel cylinders. This versatility allows you to select the perfect solution for your specific application, ensuring optimal performance and efficiency.
- 4Festo's commitment to quality is evident in the QS-1/2-12-20 cylinder. With a focus on simplicity and cost-effectiveness, this product is available for immediate delivery and comes with transparent pricing and order tracking, making procurement processes seamless.
- 5The Festo QS-1/2-12-20 cylinder is supported by comprehensive documentation and training resources. This ensures that you can easily integrate the product into your system and maintain it effectively, reducing downtime and increasing overall productivity.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Parameter | Value | Parameter | Value |
---|---|---|---|
Size | Standard | Nominal width | 11mm |
Type of seal on screwed plug | Coating | Mounting position | Any |
Design | Straight design | Pack size | 20 |
Structural design | Push-pull principle | Operating pressure for entire temperature range | -13.775psi 87psi |
Temperature-dependent operating pressure | -13.775psi 203psi | Information on operating pressure | Water: max. 0.6 MPa at max. 50 °C |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) | Information on operating and pilot media | Operation with oil lubrication possible |
Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Cleanroom class | Class 4 according to ISO 14644-1 | Ambient temperature | -10°C 80°C |
Nominal tightening torque | 26Nm | Tolerance for nominal tightening torque | ± 20% |
Product weight | 44g | Type of mounting | External hexagon, AF 21 |
Pneumatic connection 1 | External thread R1/2 | Pneumatic connection 2 | for pneumatic tubing outside diameter 12 mm |
Releasing ring color | Blue | Note on materials | RoHS-compliant |
Housing material | Brass, nickel-plated | Releasing ring material | POM |
Material of tubing seal | NBR | Material of tube retaining claw | High-alloy stainless steel |
Manufacturer ID | 130684 |
Specifications may be subject to change without notice
