Product Model
qsl-6-100
Selling Points
- 1The Festo QSL-6-100 push-in L-connector is designed for standard 3.6 mm tubing, ensuring a secure and reliable connection in various pneumatic systems.
- 2This product operates within a temperature range of -10°C to 80°C and supports operating pressures from -0.95 to 6 bar, making it versatile for different applications.
- 3The QSL-6-100 features a push-pull principle, allowing for easy assembly and disassembly without the need for tools, enhancing user convenience.
- 4The connector is made from high-quality materials, including PBT housing and POM release ring, ensuring durability and resistance to corrosion (CRC class 1).
- 5Suitable for both compressed air and water applications, this push-in L-connector conforms to ISO 8573-1:2010 and is RoHS compliant, meeting stringent industry standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Standard | Nominal width | 5mm |
Mounting position | Any | Design | L-shape |
Pack size | 100 | Structural design | Push-pull principle |
Operating pressure for entire temperature range | -13.775psi 87psi | Temperature-dependent operating pressure | -13.775psi 203psi |
Information on operating pressure | Water: max. 0.6 MPa at max. 50 °C | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) |
Information on operating and pilot media | Operation with oil lubrication possible | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Cleanroom class | Class 4 according to ISO 14644-1 |
Ambient temperature | -10°C 80°C | Product weight | 7.3g |
Pneumatic connection 1 | For pneumatic tubing outside diameter 6 mm | Pneumatic connection 2 | for pneumatic tubing outside diameter 6 mm |
Releasing ring color | Blue | Note on materials | RoHS-compliant |
Housing material | PBT | Releasing ring material | POM |
Material of tubing seal | NBR | Material of tube retaining claw | High-alloy stainless steel |
Manufacturer ID | 130741 |
Specifications may be subject to change without notice
