Festo QSL-V0-8 Push-in L-Fitting Specifications

Selling Points

1The Festo QSL-V0-8 push-in L-fitting features a nominal width of 4.6 mm and is designed for standard pneumatic connections.
2This fitting is made from PBT-reinforced material, ensuring high durability and resistance to corrosion, with a CRC of 2 - Moderate corrosion stress.
3The QSL-V0-8 operates within a temperature range of 0°C to 60°C and supports operating pressures from -0.95 bar to 10 bar, making it versatile for various applications.
4It includes a push-pull principle design with a black releasing ring and is compatible with compressed air as per ISO 8573-1:2010, as well as water according to the manufacturer's declaration.
5The product is RoHS-compliant and has a nickel-plated brass threaded plug, ensuring high-quality and reliable performance in pneumatic systems.

Detailed engineering parameters based on manufacturer documentation

Parameter	Value	Parameter	Value
Size	Standard	Nominal width	7.2mm
Material fire test	UL94 V-0 (housing) UL94 V-0 (releasing ring)	Design	L-shape
Pack size	10	Structural design	Push-pull principle
Operating pressure for entire temperature range	-13.775psi 145psi	Information on operating pressure	Water: max. 0.6 MPa at max. 50 °C
Operating medium	Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free)	Information on operating and pilot media	Operation with oil lubrication possible
Corrosion resistance class (CRC)	2 - Moderate corrosion stress	LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	0°C 60°C	Product weight	13g
Pneumatic connection 1	for pneumatic tubing outside diameter 8 mm	Pneumatic connection 2	for pneumatic tubing outside diameter 8 mm
Releasing ring color	Black	Note on materials	RoHS-compliant
Housing material	PBT	Releasing ring material	PBT
Material of tubing seal	NBR	Material of tube retaining claw	High-alloy stainless steel Brass
Manufacturer ID	160541

Specifications may be subject to change without notice
