Product Model
qslv2-1/4-8
Selling Points
- 1The Festo QSLV2-1/4-8 multiple distributor offers a standard size with a nominal size of 4.3 mm, ensuring precise fitment in various pneumatic systems.
- 2This component features a coating type of seal on the screwed plug, enhancing its durability and resistance to corrosion, making it suitable for demanding industrial environments.
- 3The QSLV2-1/4-8 is designed with a push-pull principle, allowing for easy and efficient operation, reducing the complexity of pneumatic system setup.
- 4With an operating pressure range of -0.095 MPa to 6 MPa (-13.775 psi to 87 psi), this component is versatile and can handle various pressure conditions, ensuring reliable performance in different applications.
- 5The Festo QSLV2-1/4-8 is made from RoHS-compliant materials, including PBT for the housing, nickel-plated brass for the hollow bolt, and POM for the release ring, ensuring compliance with environmental regulations and durability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Standard | Nominal width | 4.3mm |
Type of seal on screwed plug | Coating | Mounting position | Any |
Structural design | Push-pull principle | Pack size | 1 |
Operating pressure for entire temperature range | -13.775psi 87psi | Temperature-dependent operating pressure | -13.775psi 203psi |
Information on operating pressure | Water: max. 0.6 MPa at 0 - 50 °C | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) |
Information on operating and pilot media | Operation with oil lubrication possible | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Ambient temperature | -10°C 80°C |
Nominal tightening torque | 9Nm | Tolerance for nominal tightening torque | ± 20% |
Product weight | 47g | No. of outlets | 2 |
No. of supply lines | 1 | Pneumatic connection 1 | External thread R1/4 |
Pneumatic connection 2 | for pneumatic tubing outside diameter 8 mm | Releasing ring color | Blue |
Note on materials | RoHS-compliant | Housing material | PBT |
Hollow bolt material | Brass, nickel-plated | Releasing ring material | POM |
Material of tubing seal | NBR | Material of tube retaining claw | High-alloy stainless steel |
Manufacturer ID | 153215 |
Specifications may be subject to change without notice
