Product Model
qslv4-1/8-8
Selling Points
- 1The Festo QSLV4-1/8-8 is a multiple distributor pneumatic connector designed for seamless connections in industrial systems, ensuring robust and reliable pneumatic integrations.
- 2This connector features a push-pull principle, allowing for easy and efficient operation, and is available in a standard size with a nominal width of 4 mm.
- 3The QSLV4-1/8-8 operates within a wide temperature range of -10°C to 80°C and supports both compressed air and water as operating media, conforming to ISO 8573-1:2010.
- 4With a nominal tightening torque of 7 Nm and a tolerance of ±20%, this connector ensures secure connections and is RoHS-compliant, making it suitable for various industrial applications.
- 5The Festo QSLV4-1/8-8 is designed with corrosion resistance in mind, featuring a CRC 1 classification and LABS (PWIS) conformity to VDMA24364-B1/B2-L, ensuring durability in harsh environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Standard | Nominal width | 4mm |
Type of seal on screwed plug | Coating | Mounting position | Any |
Structural design | Push-pull principle | Pack size | 1 |
Operating pressure for entire temperature range | -13.775psi 87psi | Temperature-dependent operating pressure | -13.775psi 203psi |
Information on operating pressure | Water: max. 0.6 MPa at 0 - 50 °C | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) |
Information on operating and pilot media | Operation with oil lubrication possible | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Ambient temperature | -10°C 80°C |
Nominal tightening torque | 7Nm | Tolerance for nominal tightening torque | ± 20% |
Product weight | 54g | No. of outlets | 4 |
No. of supply lines | 1 | Pneumatic connection 1 | External thread R1/8 |
Pneumatic connection 2 | for pneumatic tubing outside diameter 8 mm | Releasing ring color | Blue |
Note on materials | RoHS-compliant | Housing material | PBT |
Hollow bolt material | Brass, nickel-plated | Releasing ring material | POM |
Material of tubing seal | NBR | Material of tube retaining claw | High-alloy stainless steel |
Manufacturer ID | 153234 |
Specifications may be subject to change without notice
