Product Model
qsp14-ptb
Selling Points
- 1The Festo QSP14-PTB features a standard size and straight design, ensuring easy integration into various pneumatic systems.
- 2This blanking plug operates within a wide pressure range of 0.095 MPa to 1 MPa, making it versatile for different applications.
- 3Designed to work with compressed air as per ISO 8573-1:2010, it ensures reliable performance in pneumatic setups.
- 4The QSP14-PTB supports lubricated operation, enhancing its durability and efficiency in demanding environments.
- 5Meets maritime classification standards and is RoHS-compliant, making it suitable for diverse industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Standard | Mounting position | Any |
Design | Straight design | Pack size | 1 |
Operating pressure for entire temperature range | 13.775psi 145psi | Maritime classification | See certificate |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Information on operating and pilot media | Operation with oil lubrication possible |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Ambient temperature | -10°C 60°C |
Product weight | 2.7g | Type of mounting | Mounting pin |
Pneumatic connection 1 | Cartridge 14 mm | Note on materials | RoHS-compliant |
Housing material | PA | Material of tubing seal | NBR |
Manufacturer ID | 172987 |
Specifications may be subject to change without notice
