Product Model
qspllkg14-1/4-u
Selling Points
- 1The FESTO QS-1/4-1/4-I-U-M push-in fitting ensures consistent and reliable performance in pneumatic systems, making it a trusted choice for various applications.
- 2Constructed from high-quality brass, this fitting offers durability and resistance to corrosion, ensuring long-lasting performance in demanding environments.
- 3Featuring a push-in design with an internal hexagon socket, the QS-1/4-1/4-I-U-M fitting is easy to install, reducing setup time and improving efficiency.
- 4Suitable for any assembly position, this fitting can be used in a variety of applications, including pneumatic tubing and hose connections.
- 5Meets ISO 8573-1:2010 standards and is RoHS compliant, ensuring that it adheres to international quality and environmental regulations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Mini | Nominal width | 3.4mm |
Mounting position | Any | Design | L-shape, long |
Pack size | 10 | Structural design | Push-pull principle |
Operating pressure for entire temperature range | -13.775psi 145psi | Maritime classification | See certificate |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Information on operating and pilot media | Operation with oil lubrication possible |
Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Ambient temperature | -5°C 60°C | Product weight | 3.9g |
Type of mounting | Mounting pin | Pneumatic connection 1 | Cartridge 14 mm |
Pneumatic connection 2 | for pneumatic tubing outer diameter 1/4" | Ambient temperature Fahrenheit | 23°F 140°F |
Releasing ring color | Gray | Note on materials | RoHS-compliant |
Housing material | PA-reinforced | Releasing ring material | POM |
Material of tubing seal | NBR | Material of tube retaining claw | High-alloy stainless steel |
Manufacturer ID | 132944 |
Specifications may be subject to change without notice
