Product Model
qsq-1/4-6
Selling Points
- 1The Festo QSQ-1/4-6 multiple distributor operates on a reliable push-pull principle, ensuring easy and secure connections.
- 2With 4 outlets, this fitting provides efficient distribution of compressed air or water, making it perfect for various industrial applications.
- 3Designed to handle operating pressures up to 14 bar, this fitting is suitable for a wide range of pneumatic systems.
- 4Built with low corrosion stress (CRC 1), the QSQ-1/4-6 ensures durability and longevity in harsh environments.
- 5The fitting can be installed in any position, offering flexibility in system design and installation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Standard | Nominal width | 5.2mm |
Type of seal on screwed plug | Coating | Mounting position | Any |
Structural design | Push-pull principle | Pack size | 1 |
Operating pressure for entire temperature range | -13.775psi 87psi | Temperature-dependent operating pressure | -13.775psi 203psi |
Information on operating pressure | Water: max. 0.6 MPa at 0 - 50 °C | Maritime classification | See certificate |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) | Information on operating and pilot media | Operation with oil lubrication possible |
Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Ambient temperature | -10°C 80°C | Product weight | 30g |
No. of outlets | 4 | No. of supply lines | 1 |
Pneumatic connection 1 | External thread R1/4 | Pneumatic connection 2 | for pneumatic tubing outside diameter 6 mm |
Releasing ring color | Blue | Note on materials | RoHS-compliant |
Housing material | PBT | Releasing ring material | POM |
Material of tubing seal | NBR | Material of tube retaining claw | High-alloy stainless steel |
Manufacturer ID | 153288 |
Specifications may be subject to change without notice
