Festo QSQ-G1/4-6 Multiple Distributor Connector

Selling Points

1The Festo QSQ-G1/4-6 offers 4 outlets and 1 supply line, making it a versatile connector for various pneumatic applications.
2Designed with a push-pull principle, this connector ensures easy and secure connection and disconnection.
3Compatible with compressed air as per ISO 8573-1:2010 and water, making it suitable for diverse industrial needs.
4Classified with a low corrosion resistance class (CRC 1), ensuring durability in harsh environments.
5With a nominal tightening torque of 9 Nm and a tolerance of ±20%, installation is straightforward and reliable.

Detailed engineering parameters based on manufacturer documentation

Parameter	Value	Parameter	Value
Size	Standard	Nominal width	5.2mm
Type of seal on screwed plug	Sealing ring	Mounting position	Any
Structural design	Push-pull principle	Pack size	1
Operating pressure for entire temperature range	-13.775psi 87psi	Temperature-dependent operating pressure	-13.775psi 203psi
Information on operating pressure	Water: max. 0.6 MPa at 0 - 50 °C	Maritime classification	See certificate
Operating medium	Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free)	Information on operating and pilot media	Operation with oil lubrication possible Water: G-thread only possible with sealing ring type OL as additional accessory
Corrosion resistance class (CRC)	1 - Low corrosion stress	LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-10°C 80°C	Nominal tightening torque	9Nm
Tolerance for nominal tightening torque	± 20%	Product weight	35g
No. of outlets	4	No. of supply lines	1
Pneumatic connection 1	External thread G1/4	Pneumatic connection 2	for pneumatic tubing outside diameter 6 mm
Releasing ring color	Blue	Note on materials	RoHS-compliant
Housing material	PBT	Releasing ring material	POM
Material of tubing seal	NBR	Material of tube retaining claw	High-alloy stainless steel
Manufacturer ID	186263

Specifications may be subject to change without notice
