Product Model
qst3-6-4
Selling Points
- 1The Festo QST3-6-4 multiple distributor is designed with a push-pull principle, making it easy to install and operate in any mounting position.
- 2This connector features four outlets and one supply line, providing a convenient and efficient way to distribute compressed air in your industrial setup.
- 3The QST3-6-4 operates within a wide temperature range of -10°C to 80°C and supports both compressed air and water as operating media, ensuring versatility in various environments.
- 4With a corrosion resistance classification of CRC 1 (low corrosion stress), this connector is suitable for use in applications where corrosion is a concern.
- 5The Festo QST3-6-4 is RoHS compliant and made from high-quality materials like PBT for the housing, POM for the release ring, and NBR for the tube seal, ensuring durability and reliability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Standard | Nominal width | 2.5mm |
Mounting position | Any | Structural design | Push-pull principle |
Pack size | 1 | Operating pressure for entire temperature range | -13.775psi 87psi |
Temperature-dependent operating pressure | -13.775psi 203psi | Information on operating pressure | Water: max. 0.6 MPa at 0 - 50 °C |
Maritime classification | See certificate | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) |
Information on operating and pilot media | Operation with oil lubrication possible | Corrosion resistance class (CRC) | 1 - Low corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Ambient temperature | -10°C 80°C |
Product weight | 16g | No. of outlets | 4 |
No. of supply lines | 1 | Pneumatic connection 1 | For pneumatic tubing outside diameter 6 mm |
Pneumatic connection 2 | for pneumatic tubing outside diameter 4 mm | Releasing ring color | Blue |
Note on materials | RoHS-compliant | Housing material | PBT |
Releasing ring material | POM | Material of tubing seal | NBR |
Material of tube retaining claw | High-alloy stainless steel | Manufacturer ID | 153203 |
Specifications may be subject to change without notice
