Product Model
qstl-g1/2-16
Selling Points
- 1The Festo QSL-G1/2-16 push-in L-fitting offers a quick and simple installation process, making it ideal for fast-paced industrial environments.
- 2This fitting supports a wide operating temperature range of -10°C to +80°C, ensuring it can handle various environmental conditions.
- 3With a corrosion resistance classification of CRC 1, the QSL-G1/2-16 is designed to withstand low corrosion stress, extending its lifespan.
- 4Constructed from nickel-plated brass and PBT (polybutylene terephthalate), this fitting ensures durability and reliability in pneumatic applications.
- 5Featuring a male thread G1/2 and a push-in connection for tubing outside diameter of 16 mm, the QSL-G1/2-16 offers versatile connection options for various pneumatic systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | Standard | Nominal width | 13mm |
Type of seal on screwed plug | Sealing ring | Mounting position | Any |
Design | L-shape, additional push-in connector, lengthwise | Pack size | 1 |
Structural design | Push-pull principle | Operating pressure for entire temperature range | -13.775psi 87psi |
Temperature-dependent operating pressure | -13.775psi 203psi | Information on operating pressure | Water: max. 0.6 MPa at max. 50 °C |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free) | Information on operating and pilot media | Operation with oil lubrication possible Water: G-thread only possible with sealing ring type OL as additional accessory |
Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Cleanroom class | Class 4 according to ISO 14644-1 | Ambient temperature | -10°C 80°C |
Nominal tightening torque | 26Nm | Tolerance for nominal tightening torque | ± 20% |
Product weight | 89g | No. of outlets | 2 |
No. of supply lines | 1 | Type of mounting | External hexagon, AF 24 |
Pneumatic connection 1 | External thread G1/2 | Pneumatic connection 2 | for pneumatic tubing outside diameter 16 mm |
Releasing ring color | Blue | Material of screwed plug | Brass, nickel-plated |
Note on materials | RoHS-compliant | Housing material | PBT |
Releasing ring material | POM | Material of tubing seal | NBR |
Material of tube retaining claw | High-alloy stainless steel | Manufacturer ID | 186178 |
Specifications may be subject to change without notice
