Product Model

qsy-8-6-50

Manufacturer

Festo

Category

Pneumatic connectors

Product ID

1091

In Stock
Last updated: 2025/4/18
View Specifications
Festo qsy-8-6-50

Selling Points

  • 1The Festo QSY-8-6-50 push-in Y-connector is built with a robust push-pull principle, ensuring reliable and efficient pneumatic connections.
  • 2Suitable for compressed air and water, this connector adheres to ISO 8573-1:2010 standards, making it versatile for various industrial applications.
  • 3With a corrosion resistance class of CRC 1, the QSY-8-6-50 minimizes the risk of corrosion, ensuring long-lasting performance in harsh environments.
  • 4The connector's standard size and arbitrary mounting position make it easy to integrate into any pneumatic system, reducing installation time and effort.
  • 5Made from RoHS-compliant materials like PBT and POM, this connector meets stringent environmental regulations, ensuring it is safe for use in a wide range of applications.
Product Details
qsy-8-6-50
Festo

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Size
Standard
Nominal width
3.2mm
Mounting position
Any
Design
Y-shape
Pack size
50
Structural design
Push-pull principle
Operating pressure for entire temperature range
-13.775psi 87psi
Temperature-dependent operating pressure
-13.775psi 203psi
Information on operating pressure
Water: max. 0.6 MPa at max. 50 °C
Operating medium
Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free)
Information on operating and pilot media
Operation with oil lubrication possible
Corrosion resistance class (CRC)
1 - Low corrosion stress
LABS (PWIS) conformity
VDMA24364-B1/B2-L
Cleanroom class
Class 4 according to ISO 14644-1
Ambient temperature
-10°C 80°C
Product weight
13g
No. of outlets
2
No. of supply lines
1
Pneumatic connection 1
for pneumatic tubing outside diameter 8 mm
Pneumatic connection 2
for pneumatic tubing outside diameter 6 mm
Releasing ring color
Blue
Note on materials
RoHS-compliant
Housing material
PBT
Releasing ring material
POM
Material of tubing seal
NBR
Material of tube retaining claw
High-alloy stainless steel
Manufacturer ID
130813

Specifications may be subject to change without notice
