Product Model
sdbf-fds-1l-nu-k-n-m12
Selling Points
- 1High Precision Magneto-Resistive Technology: The SDBF-FDS-1L-NU-K-N-M12 uses magneto-resistive technology for precise position measurement, ensuring accurate results in various industrial settings.
- 2Fast Switching Times: With a switch-on time of 1.5 µs and a switch-off time of 0.5 µs, this sensor provides fast response times, making it ideal for applications requiring quick detection.
- 3Robust Design and Protection: Built with a robust block design and featuring an IP67 rating, the SDBF-FDS-1L-NU-K-N-M12 is designed to withstand harsh industrial environments and protect against moisture and dust.
- 4Versatile Connectivity Options: Equipped with an M12x1 A-coded connector, this sensor offers easy integration into various systems, ensuring seamless connectivity and flexibility in different applications.
- 5LED Status Indication: The sensor includes an LED for switching status indication, providing visual feedback on its operational status, enhancing user convenience and troubleshooting efficiency.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Design | Block design | Note on materials | RoHS-compliant |
Measured variable | Position | Measuring principle | Magneto-resistive |
Ambient temperature | -20°C 80°C | Ambient temperature Fahrenheit | -4°F 176°F |
Switching output | NPN | Switching element function | N/O contact |
On time | 0.0015ms | Switch-off time | 5.0E-4ms |
Max. output current | 1000mA | Max. switching capacity DC | 24W |
Voltage drop | 0.5V | Short-circuit protection | no |
DC operating voltage range | 6V 24V | Reverse polarity protection | no |
Electrical connection 1, connection type | Cable with socket | Electrical connection 1, connection technology | M12x1 A-coded as per EN 61076-2-101 |
Electrical connection 1, number of pins/wires | 3 | Connection outlet orientation | Transverse |
Color cable sheath | Gray | Material of cable sheath | PVC |
Type of mounting | Clamped | Mounting position | Any |
Housing colour | Black | Housing material | PA |
Switching status indication | LED | Ambient temperature with flexible cable installation | -20°C 80°C |
Degree of protection | IP67 NEMA 4 | LABS (PWIS) conformity | VDMA24364 zone III |
Manufacturer ID | 8161170 |
Specifications may be subject to change without notice
