Product Model
smbr-8-8/100-s6
Selling Points
- 1The SMBR-8-8/100-S6 mounting kit features a corrosion resistance class (CRC) of 4, ensuring it can withstand very high corrosion stress, making it suitable for demanding industrial environments.
- 2This mounting kit is designed for T-slot mounting, offering optional mounting positions and compatibility with piston diameters ranging from Ø8 to Ø100, providing flexibility in various applications.
- 3Constructed from high-alloy stainless steel and wrought aluminum alloy with an anodized finish, the SMBR-8-8/100-S6 ensures durability and resistance to corrosion, ensuring long-lasting performance.
- 4The SMBR-8-8/100-S6 meets LABS (PWIS) conformity and VDMA24364-B2-L standards, ensuring it is suitable for use in the production of Li-ion batteries and adheres to strict quality and safety regulations.
- 5Weighing only 20 grams, the SMBR-8-8/100-S6 is a compact and lightweight solution that can be easily integrated into various industrial automation systems, making it ideal for space-constrained applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 8 | Design | for T-slot |
Mounting position | Any | for piston ? | ?8 - ?100 |
Corrosion resistance class (CRC) | 4 - Particularly high corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
Suitability for the production of Li-ion batteries | Metals with more than 5% by mass of copper, zinc or nickel by mass are excluded from use. Exceptions are nickel in steel, chemically nickel-plated surfaces, printed circuit boards, cables, electrical plug connectors and coils | Ambient temperature | -20°C 120°C |
Product weight | 20g | Note on materials | RoHS-compliant |
Housing material | Wrought aluminum alloy Anodized High-alloy stainless steel | Material of screws | High-alloy stainless steel |
Manufacturer ID | 538937 |
Specifications may be subject to change without notice
