Product Model
smto-1-ps-s-led-24-c
Selling Points
- 1The SMTO-1-PS-S-LED-24-C proximity sensor offers magneto-inductive measuring principle, ensuring precise detection and reliable operation in various industrial settings.
- 2Constructed with robust housing materials like PC, PET, POM, PUR, Steel, and Die-cast zinc, this sensor provides a high degree of protection (IP67) against dust and water.
- 3Equipped with a 3-pin M8x1 plug connector, the sensor offers easy integration into your automation system, ensuring seamless communication and efficient operation.
- 4Designed to operate within a DC voltage range of 10-30V, this sensor is compatible with a variety of industrial control systems, making it versatile for different applications.
- 5Weighing only 20 grams, the SMTO-1-PS-S-LED-24-C is a compact and lightweight solution ideal for space-constrained automation setups, ensuring efficient use of space without compromising performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Design | Block design | Based on norm | EN 60947-5-2 |
Symbol | 00991153 | Certification | RCM compliance mark |
CE marking (see declaration of conformity) | As per EU EMC directive As per EU RoHS directive | UKCA marking (see declaration of conformity) | To UK instructions for EMC To UK RoHS instructions |
Note on materials | RoHS-compliant | Measured variable | Position |
Measuring principle | Magneto-inductive | Ambient temperature | -25°C 70°C |
Repetition accuracy | 0.2mm | Switching output | PNP |
Switching element function | N/O contact | Hysteresis | 0.1mm 1.5mm |
On time | 1ms | Switch-off time | 1ms |
Max. switching frequency | 1000Hz | Max. output current | 200mA |
Max. switching capacity DC | 6W | Voltage drop | 3V |
Inductive protective circuit | Adapted to MZ, MY and ME coils | Residual current | 0.01mA |
Short-circuit protection | Pulsed | Overload protection | Available |
DC operating voltage range | 10V 30V | Residual ripple | 10 % |
Reverse polarity protection | for all electrical connections | Electrical connection 1, connection type | Plug |
Electrical connection 1, connection technology | M8x1 A-coded as per EN 61076-2-104 | Electrical connection 1, number of pins/wires | 3 |
Electrical connection for input 1, connection pattern | 00991155 | Connection outlet orientation | Longitudinal |
Material of pin contacts | Brass, gold-plated | Type of mounting | With accessories |
Mounting position | Any | Product weight | 20g |
Housing colour | Black | Housing material | PC PET POM PUR Steel Die-cast zinc |
Switching status indication | LED yellow | Degree of protection | IP67 |
LABS (PWIS) conformity | VDMA24364-B2-L | Manufacturer ID | 151685 |
Specifications may be subject to change without notice
