Product Model
sncb-100
Selling Points
- 1The Festo SNCB-100 swivel flange is designed to conform to the ISO 15552 standard, ensuring compatibility with a wide range of pneumatic systems.
- 2This product features a low corrosion stress classification (CRC 1), making it suitable for applications where corrosion resistance is crucial.
- 3The SNCB-100 operates within an ambient temperature range of -40°C to 90°C, providing flexibility in various industrial environments.
- 4Constructed from materials that are free of copper and PTFE, the SNCB-100 is RoHS-compliant, ensuring it meets environmental regulations.
- 5With its die-cast aluminum mounting and galvanized steel bolts, the SNCB-100 offers robust and durable performance in demanding applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 100 | Based on norm | ISO 15552 |
Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
Suitability for the production of Li-ion batteries | Metals with more than 5% by mass of copper are excluded from use. Exception are printed circuit boards, cables, electrical connectors and coils | Ambient temperature | -40°C 90°C |
Product weight | 1035g | Note on materials | RoHS-compliant |
Mounting material | Die-cast aluminum | Bolt material | Steel, galvanized |
Material of bearing | Polymer | Disc material | Steel, galvanized |
Material of screws | Steel, galvanized | Fuse material | Spring steel, galvanized |
Manufacturer ID | 174395 |
Specifications may be subject to change without notice
