Product Model
vabb-l1-18
Selling Points
- 1Meets European Union's Restriction of Hazardous Substances directive.
- 2Ensures accurate valve mounting with a grid dimension of 19 mm.
- 3Classified as CRC=2, providing excellent resistance to corrosion.
- 4Suitable for operating pressures from -0.9 to 10 bar.
- 5Simple to install with a maximum tightening torque of 1.18 Nm.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width dimension | 19mm | Operating pressure | -0.9bar 10bar |
Certification | RCM compliance mark c UL us - Recognized (OL) | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Max. tightening torque for valve mounting | 1.18Nm |
Product weight | 50g | Note on materials | RoHS-compliant |
Cover plate material | Wrought aluminum alloy | Manufacturer ID | 574482 |
Specifications may be subject to change without notice
