Product Model
vabd-d3-l-gn14
Selling Points
- 1Exhaust Protection for ATEX Zones - The VABD-D3-L-GN14 is designed to provide reliable protection in Zone 1 and Zone 2 ATEX environments, ensuring safe operation in hazardous areas.
- 2Operating Pressure Range - This product operates effectively within a pressure range of 0 MPa to 1 MPa or 0 bar to 10 bar, making it versatile for various applications.
- 3Compliant with International Standards - The VABD-D3-L-GN14 meets ISO 8573-1:2010 standards for compressed air quality and is LABS (PWIS) compliant, ensuring high-quality performance.
- 4Durable Construction - Built with a degree of protection IP54, this product is designed to withstand harsh ambient temperatures ranging from -50 °C to 60 °C, making it durable for demanding conditions.
- 5Easy Installation - The VABD-D3-L-GN14 features a screw-in mounting option via a male thread, ensuring easy and secure installation in various settings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Mounting position | Any | Symbol | 00991455 |
Operating pressure | 0bar 10bar | Explosion prevention and protection | Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX) |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | LABS (PWIS) conformity | VDMA24364 zone III |
Degree of protection | IP54 | Ambient temperature | -50°C 60°C |
Product weight | 3.8g | Type of mounting | Screw-in With external thread |
Note on materials | RoHS-compliant | Vent screw material | HP PA 12 |
Manufacturer ID | 8177960 |
Specifications may be subject to change without notice
