Product Model
vabf-l1-10h-h2
Selling Points
- 1Compact Design: The VABF-L1-10H-H2 features a compact 10 mm valve size, ideal for space-constrained applications.
- 2Piloted Non-Return Function: Ensures reliable operation with a piloted non-return function, preventing backflow of compressed air.
- 3Wide Operating Pressure Range: Operates within 0.05 MPa to 0.8 MPa (0.5 bar to 8 bar), accommodating various pneumatic system pressures.
- 4Corrosion Resistance: Meets low corrosion stress standards (CRC 1) and LABS (PWIS) conformity, ensuring durability in harsh environments.
- 5Easy Mounting: Designed for tapped mounting, simplifying installation and integration into pneumatic systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Valve size | 10mm | Valve function | Unlockable non-return function |
Operating pressure | 0.5bar 8bar | Certification | c UL us - Recognized (OL) |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
Corrosion resistance class (CRC) | 1 - Low corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Ambient temperature | -5°C 60°C | Product weight | 0.4g |
Type of mounting | Tapped | Note on materials | RoHS-compliant |
Manufacturer ID | 8047364 |
Specifications may be subject to change without notice
