Product Model
vabm-b10-20-g38-5-p53
Selling Points
- 122mm grid dimension for efficient space utilization.
- 2Optional mounting position for flexible installation.
- 35 max. valve positions for reliable pneumatic control.
- 42 - Moderate corrosion stress corrosion resistance class CRC.
- 5RoHS-compliant, wrought aluminium alloy manifold rail.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width dimension | 22mm | Mounting position | Any |
Max. no. of valve positions | 5 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 352g |
Type of mounting | With mounting bracket | Pneumatic connection 1 | G3/8 |
Note on materials | RoHS-compliant | Manifold rail material | Wrought aluminum alloy |
Manufacturer ID | 576366 |
Specifications may be subject to change without notice
