Product Model
vabm-b10-25-g12-9-p53
Selling Points
- 127.5MM Grid Dimension: Precise and efficient manifold design.
- 2Optional Mounting Position: Flexible installation options for various applications.
- 39 Max Valve Positions: Supports multiple valve configurations in one manifold.
- 4Moderate Corrosion Resistance: Class cRC ensures durability in challenging environments.
- 5RoHS Compliant: Meets environmental standards with non-toxic materials.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width dimension | 27.5mm | Mounting position | Any |
Max. no. of valve positions | 9 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 832g |
Type of mounting | With mounting bracket | Pneumatic connection 1 | G1/2 |
Note on materials | RoHS-compliant | Manifold rail material | Wrought aluminum alloy |
Manufacturer ID | 8026226 |
Specifications may be subject to change without notice
