Product Model
vabm-b10-30eee-g34-2
Selling Points
- 1Equipped with G3/4 pneumatic connections for reliable air flow management.
- 2Classified as CRC 2, ensuring durability in moderate corrosion environments.
- 3Measures 32 mm in width, making it ideal for space-constrained applications.
- 4Can be mounted with through-holes, offering flexibility in installation.
- 5Meets LABS (PWIS) conformity and VDMA24364-B1/B2-L standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width dimension | 32mm | Mounting position | Any |
Max. no. of valve positions | 2 | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Product weight | 1318g |
Type of mounting | With through-hole | Pilot air port 12 | G1/8 |
Pilot air port 14 | G1/8 | Pneumatic connection 1 | G3/4 |
Pneumatic connection 3 | G3/4 | Pneumatic connection 5 | G3/4 |
Note on materials | RoHS-compliant | Manifold rail material | Wrought aluminum alloy |
Manufacturer ID | 8026431 |
Specifications may be subject to change without notice
