Product Model
vad-1/8
Selling Points
- 1The Festo VAD-1/8 vacuum generator offers high vacuum ejector characteristics, ensuring efficient operation in various applications.
- 2This vacuum generator allows for optional mounting positions, providing flexibility in installation and integration.
- 3The T-shape design of the VAD-1/8 enhances its functionality and ease of use, making it a versatile choice for different setups.
- 4Operates with compressed air according to ISO 8573-1:2010, ensuring compatibility with standard pneumatic systems.
- 5Equipped with IP65 protection, this vacuum generator is designed to withstand harsh environments and maintain reliability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Nominal width of Laval nozzle | 0.8mm | Mounting position | Any |
Ejector characteristics | High vacuum | Structural design | T-shape |
Symbol | 00991482 | Operating pressure | 21.75psi 145psi |
Max. vacuum | 80% | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
Information on operating and pilot media | Operation with oil lubrication possible (required for further use) | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Temperature of medium | -20°C 80°C | Ambient temperature | -20°C 80°C |
Type of mounting | With through-hole | Pneumatic connection 1 | G1/8 |
Pneumatic connection 3 | G1/8 | Vacuum connection | G1/8 |
Housing material | Die-cast aluminum | Manufacturer ID | 14015 |
Specifications may be subject to change without notice
