Product Model
vad-me-3/8
Selling Points
- 1The Festo VAD-ME-3/8 vacuum generator delivers high vacuum levels, making it suitable for demanding applications.
- 2The device can be mounted in any position, offering flexibility in installation and integration.
- 3Integrated electric on-off valves provide precise control over the vacuum operation, enhancing efficiency and reliability.
- 4Designed to operate with compressed air according to ISO 8573-1:2010 [7:4:4], ensuring consistent performance.
- 5The device features an IP65 protection class, ensuring it is dust-protected and suitable for various industrial environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Nominal width of Laval nozzle | 2mm | Mounting position | Any |
Ejector characteristics | High vacuum | Integrated function | Shut off valve, electric |
Structural design | T-shape | Symbol | 00991492 |
Operating pressure | 1.5bar 8bar | Max. vacuum | 85% |
Duty cycle | 100% | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
Information on operating and pilot media | Operation with oil lubrication not possible | LABS (PWIS) conformity | VDMA24364-B2-L |
Temperature of medium | 0°C 40°C | Degree of protection | IP65 |
Ambient temperature | 0°C 40°C | Product weight | 242g |
Electrical connection | Plug | Type of mounting | With internal thread |
Pneumatic connection 1 | G1/4 | Vacuum connection | G3/8 |
Housing material | Aluminum | Manufacturer ID | 35556 |
Specifications may be subject to change without notice
