Product Model
vas-100-1/4-nbr
Selling Points
- 1The Festo VAS-100-1/4-NBR vacuum suction cup features a nominal width of 4 mm and a suction cup diameter of 100 mm, ensuring precise and effective handling in various applications.
- 2With an effective suction cup diameter of 85 mm, this suction cup offers robust and reliable performance, making it ideal for demanding tasks in automation.
- 3The VAS-100-1/4-NBR is designed with a round, flat suction cup shape and a top connection position, providing easy integration into your automation systems.
- 4This vacuum suction cup operates within a pressure range of 0.095 MPa to 0 MPa (or 0.95 bar to 0 bar), ensuring optimal performance under various operating conditions.
- 5The Festo VAS-100-1/4-NBR is part of Festo's comprehensive product range, offering standardized products that simplify product selection, reduce warehousing, and enhance customer satisfaction.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Nominal width | 4mm | Suction cup diameter | 100mm |
Effective suction cup diameter | 85mm | Connection position | Top |
Symbol | 00991485 | Suction cup shape | Round, flat |
Operating pressure | -13.775psi 0psi | Nominal operating pressure | -10.15psi |
Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | LABS (PWIS) conformity | VDMA24364-A1-L |
Ambient temperature | -20°C 80°C | Breakaway force at 70% vacuum | 397N |
Holding force at nominal operating pressure | 397N | Mounting thread | G? |
Suction cup mounting | G 1/4 | Vacuum connection | G1/4 |
Color | Black | Shore hardness | 70 +/- 5 |
Material of screwed plug | Die-cast zinc | Note on materials | RoHS-compliant |
Suction cup material | NBR | Manufacturer ID | 34586 |
Specifications may be subject to change without notice
