Product Model
vas-55-1/4-pur-b
Selling Points
- 1The Festo VAS-55-1/4-PUR-B vacuum suction cup offers height compensation of 3.5 mm, ensuring stable and consistent performance in various applications.
- 2With a nominal width of 4 mm and a suction cup diameter of 55 mm, this suction cup provides a robust and reliable grip for handling tasks.
- 3The effective suction cup diameter is 44.7 mm, allowing for efficient and precise handling of objects in automation processes.
- 4The suction cup volume is 8.01 cm³, making it suitable for a wide range of applications requiring moderate to high suction power.
- 5Designed with quality and reliability in mind, the Festo VAS-55-1/4-PUR-B suction cup is part of Festo's commitment to delivering high-quality automation solutions.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Suction cup height compensation | 3.5mm | Nominal width | 4mm |
Suction cup diameter | 55mm | Suction cup volume | 8.01cm3 |
Effective suction cup diameter | 44.7mm | Connection position | Top |
Mounting position | Any | Symbol | 00991485 |
Suction cup shape | Round, flat | Operating pressure | -13.775psi 0psi |
Nominal operating pressure | -10.15psi | Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-A1-L |
Ambient temperature | -20°C 60°C | Holding force at nominal operating pressure | 110N |
Product weight | 30g | Type of mounting | Via vacuum connection |
Vacuum connection | G1/4 | Color | Blue |
Shore hardness | 60 +/- 5 | Material of screwed plug | Die-cast zinc |
Note on materials | RoHS-compliant | Suction cup material | PUR |
Manufacturer ID | 1396095 |
Specifications may be subject to change without notice
