Product Model
vasb-125-3/8-nbr
Selling Points
- 1The Festo Vasb-125-3/8-Nbr is designed for precision in automation applications, ensuring reliable performance and minimal downtime.
- 2This component is part of Festo's extensive range of high-quality automation solutions, offering a seamless integration with other Festo products.
- 3The detailed parameterization of the Vasb-125-3/8-Nbr allows for customized settings, making it adaptable to various industrial automation needs.
- 4With its robust design and durable materials, the Vasb-125-3/8-Nbr provides long-lasting performance in demanding industrial environments.
- 5The comprehensive documentation available on the Festo website ensures easy installation and maintenance, reducing the overall cost of ownership.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Nominal width | 7mm | Suction cup diameter | 125mm |
Effective suction cup diameter | 125mm | Connection position | Top |
Symbol | 00991485 | Suction cup shape | Round bellows, 1.5 convolutions |
Operating pressure | -13.775psi 0psi | Nominal operating pressure | -10.15psi |
Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | LABS (PWIS) conformity | VDMA24364-A1-L |
Ambient temperature | -20°C 80°C | Breakaway force at 70% vacuum | 606N |
Holding force at nominal operating pressure | 606N | Mounting thread | G3/8 |
Suction cup mounting | G3/8 | Vacuum connection | G3/8 |
Color | Black | Shore hardness | 60 +/- 5 |
Material of screwed plug | Die-cast zinc | Note on materials | RoHS-compliant |
Suction cup material | NBR | Manufacturer ID | 152609 |
Specifications may be subject to change without notice
