Product Model
vasb-40-1/4-si-b

Selling Points
- 1The Festo VASB-40-1/4-SI-B is a high-performance pneumatic valve designed for precise control in industrial automation systems. It offers reliable operation and minimal energy consumption, making it ideal for various applications.
- 2This valve features standardized dimensions and mounting interfaces, ensuring easy integration into existing systems. Its compact design and lightweight construction enhance flexibility in system layout.
- 3The VASB-40-1/4-SI-B is part of Festo's extensive range of pneumatic components, including cylinders, grippers, and fittings. This comprehensive portfolio supports a wide range of handling applications.
- 4Festo's pneumatic valves, like the VASB-40-1/4-SI-B, utilize advanced technologies such as IO-Link for simplified communication with sensors and actuators. This reduces complexity and enhances system efficiency.
- 5The VASB-40-1/4-SI-B is built to meet industry standards, ensuring high-quality performance and durability. Festo's commitment to quality is reflected in its rigorous testing and manufacturing processes.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Parameter | Value | Parameter | Value |
---|---|---|---|
Suction cup height compensation | 13.7mm | Nominal width | 4mm |
Suction cup diameter | 40mm | Suction cup volume | 11.11cm3 |
Connection position | Top | Mounting position | Any |
Symbol | 00991485 | Suction cup shape | Round bellows, 1.5 convolutions |
Operating pressure | -13.775psi 0psi | Nominal operating pressure | -10.15psi |
Operating medium | Atmospheric air based on ISO 8573-1:2010 [7:-:-] | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
LABS (PWIS) conformity | VDMA24364 zone III | For use in the food industry | See supplementary material information |
Ambient temperature | -40°C 200°C | Holding force at nominal operating pressure | 58N |
Product weight | 18g | Type of mounting | Via vacuum connection |
Vacuum connection | G1/4 | Color | Transparent |
Shore hardness | 60 +/- 5 | Material of screwed plug | Wrought aluminum alloy |
Note on materials | RoHS-compliant | Suction cup material | VMQ (silicone) |
Manufacturer ID | 1372910 |
Specifications may be subject to change without notice
