Product Model
vave-c8-1r8
Selling Points
- 1LED Signal Status Display: Real-time monitoring of adapter status.
- 224V Nominal Operating Voltage DC: Compatible with a wide range of electrical systems.
- 3IP65 Protection: Robust against dust and water, ensuring reliable operation in various environments.
- 4Moderate Corrosion Resistance Class CRC 2: Durable against moderate corrosion stress.
- 5Optional Mounting Position: Flexible installation options for easy integration into various systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Signal status display | LED | Nominal operating voltage DC | 24V |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B1/B2-L |
Degree of protection | IP65 as per IEC 60529 | Ambient temperature | -5°C 60°C |
Mounting position | Any | Tightening torque | 0.25Nm |
Product weight | 3.5g | Electrical connection | 3-pin/2-pin M8 / - Plug/socket |
Protective earth connection | Not available | Type of mounting | On air solenoid valve with M2 central screw |
Note on materials | RoHS-compliant | Housing material | PA |
Material of pin contacts | Bronze | Manufacturer ID | 571686 |
Specifications may be subject to change without notice
