Product Model
vffg-t-m5-7
Selling Points
- 1Precision Air Control: The Festo VFFG-T-M5-7 flow control valve ensures precise air control with a standard nominal flow rate of 19.1L/min.
- 2Robust Construction: Made from PA material with a hollow bolt, this valve is durable and resistant to wear.
- 3Compliant with Standards: Meets VDMA24364-B1/B2-L lABS (PWIS) conformity and RoHS-compliant for environmental safety.
- 4Versatile Mounting Options: Easy to mount via thread type, providing flexibility in installation.
- 5Wide Operating Range: Operates effectively within -0.9 to 10 BAR pressure and -5°C to 60°C ambient temperature.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Valve function | Flow control function | Type of mounting | With thread |
Standard nominal flow rate in flow control direction | 19.1l/min | Operating pressure | -0.9bar 10bar |
Ambient temperature | -5°C 60°C | Nominal width | 0.7mm |
b-value | 0.5 | C value | 0.07l/sbar |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] | Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
LABS (PWIS) conformity | VDMA24364-B1/B2-L | Storage temperature | -20°C 60°C |
Product weight | 0.5g | Note on materials | RoHS-compliant |
Hollow bolt material | PA | Manufacturer ID | 8025711 |
Specifications may be subject to change without notice
