Product Model
ysrw-7-10
Selling Points
- 1The YSRW-7-10 features a self-adjusting cushioning system with a soft characteristic curve, ensuring optimal performance in various operating conditions.
- 2With a corrosion resistance classification of CRC 2, this shock absorber is designed to withstand moderate corrosion stress, making it suitable for harsh industrial environments.
- 3The YSRW-7-10 can be mounted in any position, offering flexibility in system design and installation.
- 4This shock absorber features a short reset time of 0.2 seconds at room temperature and 1 second at minimum ambient temperature, ensuring quick recovery and efficient operation.
- 5With a stroke length of 10 mm and a compact body length of 41 mm, the YSRW-7-10 is ideal for applications where space is limited, such as in pneumatic systems and actuators.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Size | 7 | Stroke | 10mm |
Cushioning | Self-adjusting Soft characteristic curve | Mounting position | Any |
Position sensing | None | Symbol | 00991495 |
Max. impact velocity | 3m/s | Reset time at room temperature | 0.2s |
Reset time at min. ambient temperature | 1s | Mode of operation | Pushing Single-acting |
Corrosion resistance class (CRC) | 2 - Moderate corrosion stress | LABS (PWIS) conformity | VDMA24364-B2-L |
Ambient temperature | -10°C 80°C | Cushioning length | 10mm |
Max. stop force | 300N | Max. energy absorption per stroke | 2.5J |
Max. energy absorption per hour | 15000J | Max. residual energy | 0.01J |
Resetting force | 1.2N | Min. insertion force | 10N |
Product weight | 18g | Load range | 5kg |
Type of mounting | With lock nut | Note on materials | RoHS-compliant |
Seals material | NBR | Housing material | High-alloy steel |
Piston rod material | High-alloy steel | Manufacturer ID | 191193 |
Specifications may be subject to change without notice
