Product Model
FBSR 1/6/11/14-8
Selling Points
- 1The FBSR 1/6/11/14-8 features a compact design with a width of 129.5 mm, ideal for space-constrained applications.
- 2With 16 non-adjacent positions and a pitch of 8.2 mm, this plug-in bridge ensures secure and reliable electrical connections.
- 3Built with high-quality materials, the FBSR 1/6/11/14-8 offers durability and long-lasting performance in demanding environments.
- 4The plug-in bridge is designed for easy installation, reducing setup time and minimizing the risk of errors.
- 5Suitable for various applications, including industrial automation and control systems, this plug-in bridge provides versatility and flexibility.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Product type | Jumper | Number of positions | 16 |
Pitch | 8.2 mm | Article revision | 02 |
Maximum load current | 32 A (The current values for the jumpers can deviate when used in different modular terminal blocks. The precise values can be found in the accessories data for the respective modular terminal blocks.) | Maximum load current | 32 A (The current values for the jumpers can deviate when used in different modular terminal blocks. The precise values can be found in the accessories data for the respective modular terminal blocks.) |
Width | 129.5 mm | Height | 30 mm |
Depth | 30 mm | Pitch | 8.2 mm |
Color | red (RAL 3001) | Material | Copper |
Flammability rating according to UL 94 | V0 | Insulating material | PA |
Pin assignment | 1, 6, 11, 14 | Mounting type | Plug-in mounting |
Specifications may be subject to change without notice
