Product Model

FL CB IF

Manufacturer

Phoenix Contact

Category

Unclassified

Product ID

19363

In Stock
Last updated: 2025/4/24
View Specifications
Phoenix Contact FL CB IF

Selling Points

  • 1Auto negotiation and autocrossing detection simplify installation and setup.
  • 2Local diagnostic indicators with LEDs for easy troubleshooting.
  • 3Five RJ45 ports supporting 10/100 Mbps transmission speed on all ports.
  • 4Quality of Service (QoS) prioritization for critical automation protocols.
  • 5PROFINET conformance Class A for real-time data exchange in industrial environments.
Product Details
FL CB IF
Phoenix Contact

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Product type
Media converter
Type
Stand-Alone
Electrical isolation
Logics / Supply / Port 1 / Port 2 / FE
Local diagnostics
LINK Port 1 Link status Port 1 Green LED LINK Port 2 Link status Port 2 Green LED ACT Port 1 Telegrams received at Port 1 Yellow LED ACT Port 2 Link status Port 2 Yellow LED
Test voltage
500 V AC
Transmission medium
Copper FO
Supply voltage
24 V DC
Supply voltage range
18.5 V DC ... 30.2 V DC
Power supply connection
Via COMBICON, max. conductor cross section 2.5 mm²
Residual ripple
3.6 V
Typical current consumption
1.01 A (output current = 1 A)
Connection method
4-pos. COMBICON
Width
67 mm
Height
90 mm
Depth
39 mm
Color
green
Housing material
PA V0, color green
Degree of protection
IP20
Ambient temperature (operation)
0 °C ... 55 °C (non-condensing)
Ambient temperature (storage/transport)
-25 °C ... 70 °C
Permissible humidity (operation)
10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport)
10 % ... 95 % (non-condensing)
Vibration (operation)
in acc. with IEC 60068-2-6: 5g, 150 Hz
Electromagnetic compatibility
Conformance with EMC directive 89/336/EC
Conformance with EMC directives
IEC 61000-6-2 IEC 61000-4-2 (ESD) Criterion B IEC 61000-4-3 (immunity to radiated interference) Criterion A IEC 61000-4-4 (burst) Criterion A IEC 61000-4-5 (surge) Criterion A IEC 61000-4-6 (immunity to conducted interference) Criterion A IEC 61000-4-8 (immunity to magnetic fields) Criterion A EN 55022 (emitted interference) Criterion A
Free from substances that could impair the application of coating
In acc. with VW specification
Electrical isolation
Logics / Supply / Port 1 / Port 2 / FE
Mounting type
DIN rail mounting

Specifications may be subject to change without notice
