Product Model

FLK 16

Manufacturer

Phoenix Contact

Category

Unclassified

Product ID

17199

In Stock
Last updated: 2025/4/18
View Specifications
Phoenix Contact FLK 16

Selling Points

  • 1High-Quality IDC/FLK Socket Strips: The FLK 16/EZ-DR cable includes two 16-position IDC/FLK socket strips for reliable connections.
  • 2Durable PVC Sheath: Constructed with a semi-rigid PVC sheath, ensuring long-lasting performance in various environments.
  • 3Flexible Installation Options: Compatible with both fixed and flexible installations, offering versatility in different setups.
  • 4Wide Operating Temperature Range: Operates between -40°C and 70°C, making it suitable for a broad range of industrial applications.
  • 5High Insertion/Withdrawal Cycles: Designed to withstand over 50 insertion/withdrawal cycles, ensuring durability and reliability.
Product Details
FLK 16
Phoenix Contact

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Product type
Interface module
Number of positions
16
Overvoltage category
II
Pollution degree
2
Nominal voltage U
< 50 V AC 60 V DC
Max. current carrying capacity per branch
1 A
Connection in acc. with standard
IEC / EN
Connection method
Screw connection
Stripping length
8 mm
Screw thread
M3
Conductor cross section rigid
0.2 mm² ... 4 mm²
Conductor cross section flexible
0.2 mm² ... 2.5 mm²
Conductor cross section AWG
24 ... 12
Connection method
IDC/FLK pin strip
Number of positions
16
Pitch
2.54 mm
Status display
no
Status display present
No
Width
60 mm
Height
50 mm
Depth
58.5 mm
Color
green (RAL 6021)
Housing insulation material
Polyamide 6 green
Ambient temperature (operation)
-20 °C ... 50 °C
Ambient temperature (storage/transport)
-20 °C ... 70 °C
Standards/regulations
IEC 60664 DIN EN 50178
Mounting type
DIN rail mounting
Mounting position
any
Notes on operation
For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met.

Specifications may be subject to change without notice
